Notebook display

Notebook display

尺寸11.6“12.2“13.3“14.0“15.6“分辨率1366*7681920*10801920*12001920*10801920*10801920*1080亮度300300300300300对比度1000:11000:11000:11000:11000:1色彩饱和度72%45%72%72%72%

首页 >> Product application >> Consumer electronics
产品亮点
Matching with high gamut LED Backlight to increase NTSC up to 85% Simultaneously utilizing many kinds of technology and design to make the module boarder to extremely narrow. The advanced glass thinning technology of K&D matching with ultra thin backlight design to realize the optimized level of lighter and thinner.
Matching with high gamut LED Backlight to increase NTSC up to 85%

High resolution

Matching with high gamut LED Backlight to increase NTSC up to 85%

Simultaneously utilizing many kinds of technology and design to make the module boarder to extremely narrow.

Narrow border

Simultaneously utilizing many kinds of technology and design to make the module boarder to extremely narrow.

The advanced glass thinning technology of K&D matching with ultra thin backlight design to realize the optimized level of lighter and thinner.

Ultra-thin

The advanced glass thinning technology of K&D matching with ultra thin backlight design to realize the optimized level of lighter and thinner.

产品参数
Size11.6“13.3“14.0“15.6“16.0“
Resolution

1366*768

1920*1080

1920*1080

1920*1080

1920*10802560*1600
Brightness300300300300300
Contrast ratio1000:11000:11000:11000:11200：1
NTSC72%72% & 85%72%72%72%


特色产品
尺寸Size(inch): 13.3解 析 度 Resolution: 1920*1080界面支持Interface: EDP1.2(40pin)外 型 尺 寸 Outline(mm): 298.96(H)*176.34(V)*2.8(D)显示区尺寸Active Area(mm): 293.76(H)*165.24(V)亮度Brightness(nits): 300TYP72% (NTSC) or 95% (sRGB)TP: Option
Notebook display 13.3

Size(inch): 13.3

Resolution: 1920*1080

Interface: EDP1.2(40pin)

Outline(mm): 298.96(H)*176.34(V)*2.8(D)

Active Area(mm): 293.76(H)*165.24(V)

Brightness(nits): 300TYP

 72% (NTSC) or 95% (sRGB)

 TP: Option


尺寸Size(inch): 14解 析 度 Resolution: 1920*1080界面支持Interface: EDP1.4(30pin)外 型 尺 寸 Outline(mm): 350.66(H)*205.25(V)*3.05(D)显示区尺寸Active Area(mm): 344.16(H)*193.59(V)亮度Brightness(nits): 250TYP刷新频率Refresh Rate: 60HZ72% (NTSC) or 95% (sRGB)TP: Option
Notebook display 14

Size(inch): 14

Resolution: 1920*1080

Interface: EDP1.4(30pin)

Outline(mm): 350.66(H)*205.25(V)*3.05(D)

Active Area(mm): 344.16(H)*193.59(V)

Brightness(nits): 250TYP

Refresh Rate: 60HZ

72% (NTSC) or 95% (sRGB)

TP: Option


尺寸Size(inch):15.6解 析 度 Resolution: 1920*1080 界面支持Interface: EDP1.4(40pin)外 型 尺 寸 Outline(mm): 350.66(H)*205.25(V)*2.45(D)显示区尺寸Active Area(mm): 344.16(H)*193.59(V)亮度Brightness(nits): 300TYP刷新频率Refresh Rate: 144HZ72% (NTSC) or 95% (sRGB)TP: Option
Notebook display 15.6

Size(inch):15.6

Resolution: 1920*1080 界面支持Interface: EDP1.4(40pin)

Outline(mm): 350.66(H)*205.25(V)*2.45(D)

Active Area(mm): 344.16(H)*193.59(V)

Brightness(nits): 300TYP

Refresh Rate: 144HZ

72% (NTSC) or 95% (sRGB)

TP: Option


尺寸Size(inch):16.0解 析 度 Resolution: 2560*1600界面支持Interface: EDP1.4外 型 尺 寸 Outline(mm): 49.68（H)*224.42(V)*2.6(D)显示区尺寸Active Area(mm): 344.68(H)*215.42(V)亮度Brightness(nits): 300TYP刷新频率Refresh Rate: 120HZNTSC: 72% (NTSC) or 95% (sRGB)TP: Option
Notebook display 16.0

Size(inch):16.0

Resolution: 2560*1600

Interface: EDP1.4

Outline(mm): 496.8（H)*224.42(V)*2.6(D)

Active Area(mm): 344.68(H)*215.42(V)

Brightness(nits): 300TYP

Refresh Rate: 120HZ

NTSC:  72% (NTSC) or 95% (sRGB)

TP: Option
